Features:
• Four capacity options from 30kW to 122kW
• Titanium flow tube and heating stacks
• 316L stainless steel housing
• Compatible for salt or sea water
• Resistance up to 4 bar pressure
• Low flow pressure drop
• Ports for thermostat and dimmer
• Placement horizontally or vertically
| MODEL | L1 | L2 | L3 |
|---|---|---|---|
| G2-HE-30T | 540 mm | 426 mm | 247 mm |
| G2-HE-49T | 710 mm | 596 mm | 417 mm |
| G2-HE-85T | 840 mm | 726 mm | 547 mm |
| G2-HE-122T | 1000 mm | 886 mm | 707 mm |
| CODE | MODEL | STANDARD OUTPUT kW | PRIMARY FLOW m3/h | PRIMARY PRESSURE LOSS bar | SECONDARY FLOW m3/h | SECONDARY PRESSURE LOSS bar |
|---|---|---|---|---|---|---|
| 203.11.80 | G2-HE-30T | 30 | 1,1 | 0.061 | 10 | 2 |
| 203.11.61 | G2-HE-49T | 49 | 1,6 | 0.077 | 16 | 2 |
| 203.11.62 | G2-HE-85T | 85 | 2,4 | 0.113 | 17 | 2 |
| 203.11.63 | G2-HE-122T | 122 | 3,8 | 0.183 | 19 | 2 |
